This page shows our apparatus for concrete mixing and casting for tests.



DSCF0114



This is our largest mixer with a maximum capacity of 30 50 litres depending on the mix.

Second year students design a concrete mix and make it in this mixer.



DSCF0097DSCF0098



These are our 2 smaller concrete mixers with capacities of approximately 15 litres and 5 litres.



DSCF0021



We also have a number of high-shear mixes for mortar and paste (grouts).

DSCF0039

We have a ball mill for grinding cement and cement clinker and cement replacement materials.



DSCF0064aDSCF0010DSCF0095



These pictures shows some of our mini-beam moulds and our rack of cube and cylinder moulds.

In total we have:

12 gangs of 3 no. 50mm cube moulds

51 no. 100mm cube moulds

17 no. 150mm cube moulds

12 no. 500mm by 100mm by 100mm mini-beam moulds

15 no. 100mm diameter cylinder moulds.

Plus a large number of plastic moulds (in the left hand picture) which we now generally use in place of the metal ones.



DSCF0079



This balance has a capacity of 250 kg. In the casting area we also have a large 25kg mechanical balance and a 30kg electronic one.



DSCF0117



This is our vibrating table on which we compact most of our samples.





DSCF0111



We have two electric poker-vibrators.





DSCF0012



The curing room has several tanks which we can control to temperature.



DSCF0013



We have a number of laboratory ovens for drying samples.



DSCF0112



This saw is used for cutting the ends from cores etc.
